SONY IMX385LQR-C

SONY IMX385LQR-C SONY IMX385LQR-C



SONY IMX385
is a diagonal 8.35mm (type 1/2) CMOS image sensor with 2.13M effective pixels. It is only available in color. The IMX385 pursues picture quality at low illuminance and mounts pixels with a sensitivity of 2350mV.

        Product NameSONY IMX385LQR-C
        ManufacturerSONY
        Sensor TypeCMOS
        Shutter TypeRolling Shutter
        Recording Pixels1920(H) x 1080(V)
        Resolution2.07M
        Optical Format1/2"
        Pixel Size3.75µm x 3.75µm
        ChromaticColor
        Maximal Frame Rate @Full Resolution120fps (10bit)
        Bit Depth

        10bit
        12bit

        Interface

        sub LVDS Serial (2, 4, 8 lanes)
        MIPI D-PHY (2, 4 lanes)

        Side IlluminationFront-illumination



        Title Download
        IMX385LQR_Flyer
        Technology guide Sony Rolling Shutter
