Kit FPGA DE10-Standard Altera


O Kit DE10 Standard (P0493) tem muitos recursos que permitem aos usuários implementar uma ampla gama de circuitos projetados, desde circuitos simples até vários projetos de multimídia.

Destaca-se:
Grande capacidade de reconfiguração em conjunto com um sistema de processador de baixo desempenho e baixo consumo de energia. O SoC da Altera integra um sistema de processador rígido (HPS) baseado em ARM, que consiste em interfaces de processador, periféricos e memória.

A placa de desenvolvimento padrão DE10 inclui hardware, como memória DDR3 de alta velocidade, recursos de vídeo e áudio, rede Ethernet e muito mais!

Selo Terasic

Características:

FPGA Device

  • Cyclone V SX SoC—5CSXFC6D6F31C6N
  • 110K LEs, 41509 ALMs
  • 5,761 Kbits embedded memory
  • 6 FPGA PLLs and 3 HPS PLLs
  • 2 Hard Memory Controllers

ARM-Based Hard Processor System (HPS)

  • 925 MHz, Dual-Core ARM Cortex-A9 MPCore Processor
  • 512 KB of Shared L2 Cache
  • 64 KB of Scratch RAM
  • Multiport SDRAM Controller with Support for DDR2, DDR3, LPDDR1, and LPDDR2
  • 8-Channel Direct Memory Access (DMA) Controller

Configuration and Debug

  • Serial Configuration Device – EPCS128 on FPGA
  • On-Board USB Blaster II (Normal Type B USB Connector)

Memory Device
• 64MB (32Mx16) SDRAM on FPGA
• 1GB (2x256Mx16) DDR3 SDRAM on HPS
• MicroSD Card Socket on HPS

Communication

  • Two USB 2.0 Host Ports (ULPI Interface with USB Type A Connector) on HPS
  • USB to UART (Micro USB Type B Connector) on HPS
  • 10/100/1000 Ethernet on HPS
  • PS/2 Mouse/Keyboard
  • IR Emitter/Receiver

Connectors

  • One 40-pin Expansion Header (Voltage Levels: 3.3V)
  • One HSMC Connector(Configurable I/O Standards 1.5/1.8/2.5/3.3V)
  • One 10-Pin ADC Input Header
  • One LTC Connector (One Serial Peripheral Interface (SPI) Master ,One I2C and One GPIO Interface ) on HPS

Display

  • 24-bit VGA DAC
  • 128x64 Dots LCD Module with Backlight on HPS

Audio

  • 24-bit CODEC, Line-in, Line-out, and Microphone-In Jacks Video Input
  • TV Decoder (NTSC/PAL/SECAM) and TV-In Connector

ADC

  • Sample Rate: 500 KSPS
  • Channel Number: 8
  • Resolution: 12 bits
  • Analog Input Range : 0 ~ 4.096 V

Switches, Buttons and Indicators

  • 4 User Keys (FPGA x4)
  • 10 User Switches (FPGA x10)
  • 11 User LEDs (FPGA x10 ; HPS x 1)
  • 2 HPS Reset Buttons (HPS_RST_n and HPS_WARM_RST_n)7-Segment Display x6

Sensors

  • G-Sensor on HPS

Power

  • 12V DC Input

Para saber mais fale conosco.
