NVIDIA® Jetson AGX Xavier

NVIDIA® Jetson AGX Xavier NVIDIA® Jetson AGX Xavier

Overview

NVIDIA Jetson AGX Xavier brings data-center-class AI to embedded form factors. It combines a powerful GPU, AI accelerators, and an 8-core CPU with rich I/O for multi-sensor systems. Use it when you need more parallel inference, higher frame rates, and advanced perception on device.

Why Choose Jetson AGX Xavier?

  • Up to 32 TOPS class AI performance in a compact module
  • 8-core Arm CPU and NVIDIA GPU with Tensor Cores for modern AI workloads
  • Flexible power profiles to match thermal and battery targets
  • Camera-dense designs with CSI-2 lanes for multi-sensor pipelines
  • Mature Jetson software stack, tools, and ecosystem

Key Features

  • High throughput AI: Run multiple DNNs in parallel for perception, tracking, and analytics
  • Sensor-fusion-ready: Abundant CSI-2 and high-speed I/O for cameras, lidar, and radar
  • Rugged integration: Small footprint with integrated heat spreader simplifies mechanical design
  • Production-grade software: JetPack SDK, CUDA, TensorRT, and containerized deployment
  • Lifecycle support: Long-term availability for industrial programs

Why These Modules?

Typical Applications

  • Mobile robots and AMRs
  • Inspection and quality control
  • Industrial vehicles
  • Smart city analytic
  • Autonomous systems
  • Multi-camera vision
  • Sensor fusion and mapping

Carriers and Cameras

  • Carriers: Connect Tech Rogue and Rogue-X carrier boards for AGX Xavier
  • Camera expansion: MIPI boards for Allied Vision Alvium, FPD-Link III, SDI, and HDMI ingest
  • Storage and comms: NVMe via M.2, multiple USB 3.x, dual Ethernet options on supported carriers

Ordering Information

  • Jetson AGX Xavier: 16 GB or 32 GB module options

Contact us for availability, lead time, recommended carriers, thermal solutions, and camera kits.

Category
Interfaces
Form factor100 mm x 87 mm module with integrated thermal transfer plate
AI performance
Up to 32 TOPS class depending on model and power mode
CPU8-core Arm v8.2
GPUNVIDIA architecture with Tensor Cores
AI acceleratorsDual NVDLA engines
Memory16 GB or 32 GB LPDDR4x options
Storage32 GB eMMC on module
Camera I/OUp to 16 lanes MIPI CSI-2
High-speed I/OPCIe Gen 4, USB 3.x, Gigabit Ethernet
VideoMulti-stream 4K encode and decode
Typical powerProfile selectable in the 10 W to 30 W range

Values are typical for selection and may vary by exact module and software release.

Title
Download
Spec Sheet - Photon AI Camera Platform for NVIDIA® Jetson Xavier™ NXDownload
Spec Sheet - Quark Carrier for NVIDIA® Jetson Xavier™ NXDownload
Spec Sheet - Rudi-NX Embedded System with NVIDIA® Jetson Xavier™ NXDownload
Spec Sheet - NVIDIA® Jetson Xavier NX™ 16GB ModuleDownload
Spec Sheet - NVIDIA® Jetson Xavier NX™ ModuleDownload
