Connect Tech builds deploy-ready boards and rugged systems for edge AI, vision, and networking. The Connect Tech products portfolio spans NVIDIA® Jetson carriers, camera platforms, embedded Ethernet switches, COM-HPC and COM Express carriers, plus accessories and thermal solutions. Macnica Americas distributes and supports Connect Tech solutions with local engineering, supply chain scale, and custom design services.
The Falcon Vehicle System is a production-ready, IP67-rated edge AI compute platform powered by NVIDIA Jetson Orin NX - purpose-built for agriculture, construction, and mining vehicles. Fanless and fully sealed, Falcon mounts directly on heavy equipment and supports up to four GMSL2 cameras, dual T1 Ethernet, and CAN interfaces for seamless vehicle integration. Launched at CONExpo 2026 and named Best-in-Show at embedded world Germany 2026 in AI and Machine Learning, Falcon is market-validated and ready for deployment.
Robotics, AMR, inspection, traffic and smart city, defense ISR, agriculture, construction, and autonomous machines.
Tell us your module target, camera stack, and I/O needs. We will align a carrier or system, plus thermal, cabling, and BSP.
Product | Type | Dimensions | Networking | Camera add-ons | Notes |
|---|---|---|---|---|---|
| Gauntlet | Carrier board | 155 × 125 mm | High-speed Ethernet via Thor I/O | Compatible with FPD-Link III, HDMI, SDI, MIPI kits | Full-featured Thor carrier for high sensor count edge AI |
Product | Focus | Dimensions | Networking | Notable I/O | Notes |
|---|---|---|---|---|---|
| Forge | Commercial-deployable | 155 × 125 mm | Up to dual 10GBASE-T plus dual GbE | DisplayPort, NVMe, USB 3.x | Compact AGX Orin and Industrial support |
| Rogue | High-I/O | Compact | Dual 10GbE | Multiple USB 3.x, HDMI, camera expansion header | Full-featured, production ready |
| Rogue-RX | Ruggedized | 92 × 108.2 mm | Dual 10GBASE-T with locking | USB 3.2 Gen2, HDMI, rugged pin headers | Built for harsh environments |
Product | Class | Protection | I/O highlights | Notes |
|---|---|---|---|---|
| Anvil-RX | Rugged edge system | IP67 | Sealed M12 I/O, power filtering | Outdoor and vehicle deployments |
| Sentry-X2 | MIL-focused system | MIL-oriented design | SDI in and out, mixed-speed Ethernet | Tactical edge compute |
| AGX Orin Inference Server | 2U deep learning server | Rackmount | Managed 10G uplinks, OOB management | Multi-module, low-wattage cluster |
Add-On | Inputs | Works with | Notes |
|---|---|---|---|
| HDMI Camera Platform (JCB010) | HDMI to CSI-2 | Rogue and Forge | Dual micro HDMI plus dual 30-pin headers |
| SDI Vision Platform (JCB003) | SDI to CSI-2 | Selected AGX carriers and systems | Ultra-low latency ingest |
| Allied Vision MIPI board | Up to 6 MIPI | Rogue, Rogue-X, Forge | For Alvium sensors, device tree support |
| FPD-Link III board | Multi-camera over coax | Rogue, Rogue-X, Forge | Power over coax, long cable runs |
Product | Focus | Camera I/O | Networking | Expansion and notes |
|---|---|---|---|---|
| Hadron-DM | Ultra-small, rugged | Dual MIPI CSI-2 | 1 × GbE | Compact SODIMM-class carrier |
| Super Hadron-DM | Ultra-small with Super Mode | 2 × 4-lane MIPI | 1 × GbE | Adds Super Mode, M.2 NVMe 2242 |
| Lepton | FPD-Link III hub | 4 × FPD-Link III | Dual GbE | 4 × USB 3.0, HDMI, NVMe and M.2 |
| Boson-22 | Compact vision carrier | 4 × 22-pin MIPI | Dual GbE | Dual USB, NVMe, 9–36 V input |
Product | Class | Protection | I/O highlights | Notes |
|---|---|---|---|---|
| Polaris | Rugged edge system | IP67 | Vision-heavy I/O set | Robotics and smart city |
| Rudi-NX | Compact system | Compact chassis | Dual GbE, camera options | Scales with Orin NX performance |
Add-on | Works with | Notes |
|---|---|---|
| Photon AI Camera Platform | Orin NX | PoE-PD uplink, smart-camera builds |
Product | Focus | Networking | Notable I/O | Notes |
|---|---|---|---|---|
| Rogue | Full-featured | Dual Ethernet options | Multi-camera, HDMI, expansion header | Proven deployable platform |
| Rogue-X | High I/O and PCIe | Dual Ethernet options | PCIe expansion, vision-ready | Companion to camera boards |
Product | Focus | Networking | Camera I/O | Notes |
|---|---|---|---|---|
| Quark | Ultra-small SODIMM carrier | Dual GbE | 2 × MIPI CSI-2 | Compatible with TX2 NX, Nano, Xavier NX |
Product | Class | Notes |
|---|---|---|
| Rudi-NX | Compact system | About 21 TOPS, rich I/O and storage |
| Photon AI Camera Platform | Smart-camera carrier | PoE-PD uplink, housing-friendly layout |
Product | Focus | Dimensions | Camera I/O | Notable I/O | Notes |
|---|---|---|---|---|---|
| Orbitty | Tiny, general-purpose | 87 × 50 mm | Single MIPI option | HDMI, GbE, USB 3.0, microSD | Robotics and UGV-friendly |
| Spacely | Multi-camera | Compact | Up to 6 × MIPI CSI-2 | GPS or GNSS expansion | Situational awareness builds |
| Sprocket | Lowest-profile | Very compact | 1 × 4-lane MIPI | USB OTG, UART, I²C, GPIO | Space-constrained payloads |
| Quasar | Orbitty with more I/O | 187 × 50 mm | 1 × 4-lane MIPI | 2 × USB 3.0, CAN, SATA, HDMI 2.0 | More storage and expansion |
Product | Standard | I/O highlights | Notes |
|---|---|---|---|
| COM-HPC Carrier | Client A, B, C | 2 × 2.5 GbE, USB-C 3.2, multiple M.2, mini DisplayPort | Small form factor, extended temperature options |
| COM-HPC Mini Carrier | COM-HPC Mini | 4 × 2.5 GbE, 4 × USB 3.2, M.2 M and E, serial, CAN | Rugged locking connectors |
Product | Standard | Networking | Expansion | Notes |
|---|---|---|---|---|
| Type 7 Carrier Board | COM Express Type 7 | Dual 10GbE SFP+ plus 2 × GbE | M.2 NVMe, USB 3.0, mini PCIe | Enterprise-class edge compute |
| Type 7 plus GPU System | COM Express Type 7 with GPU | High-speed backplane | High-end NVIDIA GPUs | Rugged small form factor system |
Product | Form factor | Key I/O | Notes |
|---|---|---|---|
| PCIe/104 Qseven Carrier | PC/104 (PCIe/104) | SATA, USB, GbE, LVDS, VGA, serial | Integrates most Qseven modules |
| PCI-104 Qseven Carrier | PC/104 (PCI-104) | PCI-104 expansion | Same I/O family as above |
| Ultra-Lite and Lite Qseven | Compact | Mini PCIe, SIM options | Low cost, flexible carriers |
Product | Standard | Key I/O | Notes |
|---|---|---|---|
| SMARC 2.0 Carrier | SMARC 2.0 | 2 × HDMI, 2 × GbE, USB 3.0 and 2.0, dual CSI-2 | Small layout, wide temperature options |
| SMARC/SL | SMARC 1.1 and 2.0 | mPCIe and mSATA, GbE, HDMI, CSI | Very small footprint, extended temperature |
Product | Standard | Key I/O | Notes |
|---|---|---|---|
| SMARC 2.0 Carrier | SMARC 2.0 | 2 × HDMI, 2 × GbE, USB 3.0 and 2.0, dual CSI-2 | Small layout, wide temperature options |
| SMARC/SL | SMARC 1.1 and 2.0 | mPCIe and mSATA, GbE, HDMI, CSI | Very small footprint, extended temperature |
