RM-QCS610

Qualcomm RM-QCS610 Compact Snapdragon SOM

Find the Qualcomm RM-QCS610 Compact Snapdragon SOM at Macnica Americas. With advanced performance in a small footprint, it's ideal for innovative designs.

IBASE Brings the Power, Versatility and Efficiency of the Broadcom Snapdragon Processor to your Project in an Industrial SMARC SOM

It’s tough to beat the capabilities of a Qualcomm Snapdragon-based SOM in a business card sized SMARC form factor utilizing 4K video with codec, Adreno GPU, MIPI interfaces and much more. From IBASE, this powerful and compact Snapdragon SOM also has a baseboard available for product development.

Key Features

  • Qualcomm QCS610 SoC (processor)
  • Up to 4GB LPDDR4, 32GB eMMC
  • 4k video capture and playback at 30fps
  • 3.15 TOPS @caffe
  • Validated with Linux open embedded / Android 10
  • Long life time supply with Qualcomm solution
  • Complaint with SMARC™ 2.1
  • Wide operating temp: -30C to +85C

Technical Details

The following includes technical and ordering information for the RM-QCS610 SOM.

Form Factor
SMARC™ 2.1
Processor
QCS610
Kryo Gold: Dual high-performance cores 2.2 GHz
Kryo Silver: Hexa low-power cores 1.8 GHz
Flash Memory
32GB eMMC
Display
1x HDMI up to 1920 x 1080 at 60 Hz
1x MIPI DSI
Video Codec
4K30 8-bit H.264/HEVC/VP8/VP9
Multi-format codec up to 4K30 video encode
Multi-stream codec (4K30) (HEVC) + 720p30 (YUV)
+ 480p30 (VA-YUV)
Dual 14-bit image signal processing (ISP) + Lite ISP:
24 MP (2x IFE + 1x IFE Lite, 16 + 16 + 2 MP), 4K30,
MCTF, SHDR, C-PHY, DPHY
4K30 8-bit H.264/HEVC/VP8
Graphics
Adreno 612; 845 MHz,
3D graphics accelerator with 64-bit addressing
Audio Interface
1x I2 S
LAN
1x GbE Lan
USB
3x USB 2.0 ( Type-A)
1x USB 3.0 (Gen-1 with OTG support)
Image Capture Interface
1x MIPI CSI (2 lane) + 1x MIPI CSI (2 or 4 lane)
Serial Interface
1x UART, 2x SPI
Media Interface
N/A
PCI-E
N/A
SATA
N/A
GPIO
12x GPIO
I²C
4x I²C
Others
Wireless WCN3980 (optional)
CAN Bus
N/A
Dimensions
82 mm x 50 mm (3.2” x 2”)
Environment
Humidity: 0 % to 90 % RH at 60° C (non-condensing)
Shock: Non-Operating: 1G, 15 mins (x-, y-, z-axis)
Vibration: Non-operating: 3 Hz to 500 Hz, 15 mins
Operating Temperature
-30°C ~ +85°C
OS Support
Linux open embedded / Other OS (by request)
Certification
CE/ FCC Class-A

Ordering Information

RM-QCS610L
Industrial grade SMARC™2.1 CPU module
Qualcomm QCS610 SoC, 2GB LPDDR4, 16GB TLC
eMMC
RM-HSK-Q
Heat sink for IBASE RM-QCS610 series module
