SupremeStore

Graid
SupremeStore

To further enhance high-performance storage, Graid Technology offers the SupremeStore clustered storage system. It features a dual-controller high-availability (HA) architecture, combining SupremeRAID™ SR-1010 with BeeGFS and InfiniBand interconnects, achieving transfer rates of up to 80 GB/s. This solution supports linear scalability up to 20 SSDs and horizontal expansion to 1000+ nodes, making it an ideal fit for AI, machine learning (ML), and HPC workloads—perfectly suited for model training and inference environments.

Product Specification ( 3 YEARS WARRANTY )

  • Processor: Single Socket E (LGA-4677) 5th/4th Gen Intel® Xeon® Scalable processor, up to 350W TDP
  • Memory: Supports 8 DIMMs per node with 1DPC. Up to 2TB DDR5-5600 ECC memory with 8× 256GB 3DS RDIMM
  • Drive Bays: 24 x Hot-swap Dual Port Gen5 U.2 NVMe SSD bays
  • Expansion slot: 2 x PCIe 5.0 x16 HHHL / 2 x PCIe 5.0 x8 HHHL
  • GPU Card: 2 x SR-1000-HE-FD32
  • Networking: 1 x Dedicated 1GbE Private Ethernet (Heartbeat)
  • Power Supply: Redundant Titanium 2000W Power Supplies
