IEI Puzzle Software Defined Routers
The next generation and next LEVEL of readily scalable, configurable, and performance-oriented network solutions
For 2.5G and 10G Ethernet routing, you can perform real-time updates and configuration for connections, security, VPN and advanced network functions. With the pre-installed, highly touted, open source OpenWrt OS, users can leverage over 3,500 free available software solutions for IEI’s Puzzle-M901 and Puzzle-M902.
Both Puzzle M901 and M902 come with the powerful Marvell ARM quad-core SoC has built-in acceleration for security and network operations and is well suited for handling the software defined functionality.
- Puzzle-M901: 6x 2.5 GbE ports
- Puzzle-M902: 3x 10GbE, 6x 2.5 GbE ports
Puzzle-M902 Specifications and Ordering Information
Hardware Spec.
| Form Factor | |
| Form Factor | Desktop |
| System | |
| CPU | Marvell® CN9130 quad-core Armv8 Cortex-A72 @ up to 2200 MHz |
| Cooling method / System Fan | 1 system fan |
| Physical Characteristics | |
| Dimensions (LxWxH) (mm) | 226 x140 x 50.5 |
| Storage | |
| Storage | 1 x eMMC: onboard 4 GB |
| 1 x M.2(NGFF): 2242/2280 M Key M.2 PCIe Gen. 3 x1 | |
| I/O Interface | |
| Ethernet | 3 x Fiber: 10 GbE |
| 6 x LAN: 2.5 GbE | |
| I/O Interface | 1 x External USB 3.2 Gen1x1 |
| Environment | |
| Operating Temperature | 0°C ~ 40°C (32°F ~ 104°F) |
| Storage Temperature | -20°C ~ 75°C (-4°F ~ 167°F) |
| Humidity | 5~95% non-condensing, wet bulb: 27˚C |
| Certifications | |
| Safety & EMC | CE/FCC/BSMI (BSMI safety)/VCCI, LVD |
| OS Support | |
| OS Support | OpenWrt |
Ordering Information
| PUZZLE-M902-CN1-R10 | Desktop Network Appliance with Marvell CN9130 Processor, 6 x 2.5GbE and 3 x10 GbE on Board 4GB eMMC & 1x M.2 slot, RoHS |
|---|
Package Contents
| Package Contents |
|
|---|
Puzzle-M901 Specifications and Ordering Information
Hardware Spec.
| Form Factor | |
| Form Factor | Desktop |
| System | |
| CPU | Marvell® CN9130 quad-core Armv8 Cortex-A72 @ up to 2200 MHz |
| Cooling method / System Fan | Active Fan |
| Physical Characteristics | |
| Dimensions (LxWxH) (mm) | 166.4 x 145.7 x 34 |
| Storage | |
| Storage | 1 x eMMC: onboard 4 GB |
| 1 x M.2 (NGFF): 2242 M-key M.2 PCIe Gen. 3 x 2 | |
| I/O Interface | |
| Ethernet | 6 x LAN: 2.5 GbE |
| I/O Interface | 1 x External USB 3.2 Gen1x1 |
| Environment | |
| Operating Temperature | 0°C ~ 40°C (32°F ~ 104°F) |
| Storage Temperature | -20°C ~ 75°C (-4°F ~ 167°F) |
| Humidity | 5~95% non-condensing, wet bulb: 27˚C |
| Certifications | |
| Safety & EMC | CE/FCC/BSMI (BSMI safety)/VCCI, LVD |
| OS Support | |
| OS Support | OpenWrt |
Ordering Information
| PUZZLE-M901-CN1-R10 | Desktop Network Appliance with Marvell CN9130 Processor, 6 x 2.5GbE on Board 4GB eMMC and 1x M.2 slot, RoHS |
|---|
Package Contents
| Package Contents |
|
|---|
Puzzle Software Defines Router Overview Video
