Networking & Servers

iEi’s Networking and Servers portfolio delivers versatile and scalable solutions designed for functions such as routing, firewalling, VPN, UTM, and SD-WAN. These appliances are built for open-source integration and can be customized for ODM and OEM requirements.



IEI Networking & Servers





Offerings range from:

  • Entry-level fanless or compact systems that are cost-efficient and eco-friendly
  • Performance-level rack appliances powered by Intel Core processors with features like hot-swap power supplies and modular I/O
  • Premium rack appliances using Xeon processors for enterprise and cloud applications with high throughput and flexible expansion

Highlighted Product Offerings





Entry-Level Network Appliances

PUZZLE-1100

  • Desktop appliance with Intel Atom X Series processor
  • 4 × 2.5 GbE LAN
  • DDR5 SO-DIMM and 128 GB eMMC (expandable via M.2)
  • AES-NI encryption and virtualization support









Premium Desktop Appliances

PUZZLE-3032 and PUZZLE-3034

  • Intel Atom C3000 processors
  • PUZZLE-3032: 8 × 2.5 GbE + 2 × 10 GbE, 64 GB eMMC
  • PUZZLE-3034: 8 × 2.5 GbE + 4 × 10 GbE, 64 GB eMMC



PUZZLE-IN003A and PUZZLE-IN003B

  • PUZZLE-IN003A: Atom C3000, 8 × 1 GbE + 4 × 10 GbE, bypass capability, 32 GB eMMC
  • PUZZLE-IN003B: Atom C3000, 6 × 1 GbE + 2 × 10 GbE, 2 M.2 slots, 32 GB eMMC









ARM-Based Appliances

PUZZLE-M801

  • Marvell Armada 88F8040 quad-core ARM SoC
  • 4 × 1 GbE and 2 × 10 GbE LAN
  • 1 × PCIe ×16 expansion



PUZZLE-M902 and PUZZLE-M901

  • Marvell CN9130 (Cortex-A72 / A7) with OpenWrt pre-installed
  • M902: 6 × 2.5 GbE + 3 × 10 GbE
  • M901: 6 × 2.5 GbE









1U Rackmount Appliances (Intel Platforms)

PUZZLE-5030

  • 11th Gen Intel Xeon E processor
  • 8 × 2.5 GbE, dual bypass LAN pairs
  • 2 PulM slots and 2 PCIe Gen3 slots



PUZZLE-IN001A / IN002 / IN001

  • Intel Core, Pentium, or Celeron processors
  • Options include 8 × 5 GbE, 6 × 1 GbE with PCIe ×16, or 8 × 1 GbE with PulM slots









Scalable 1U and 2U Rack Appliances (Enterprise)

PUZZLE-IN005

  • 3rd Gen Intel Xeon Scalable processor
  • 2 × 1 GbE, 8 PulM slots, PCIe ×8 expansion



PUZZLE-7030A, PUZZLE-9030, PUZZLE-9040

  • High-performance rack systems with Xeon D, AMD EPYC, or dual Xeon Scalable CPUs
  • Features include OCP slots, PCIe Gen4 connectivity, PulM expansion and U.2 storage options









Storage Servers - GRAND Series

  • 3rd Gen Intel Xeon Scalable processor
  • 2 × 1 GbE, 8 PulM slots, PCIe ×8 expansion



Network Modules - PulM Series

  • Flexible expansion through high-performance NIC modules:
    • 100 GbE: PulM-100G2SF-CX6, PulM-100G25F-E810
    • 40 GbE: PulM-40G2SF-XL710
    • 10 GbE: PulM-10G2SF, PulM-10G4SF variants
    • 1 GbE: PulM-1G4SF, PulM-1G8T and other RJ45 or bypass options
  • Additional modules include expansion cards, M.2 support, and the Mustang-QA100 crypto accelerator
