SONY IMX178LQJ is a color CMOS image sensor with a diagonal 8.92mm (type 1/1.8) and 6.44M effective pixels.
This sensor uses the STARVIS technology. It realizes high picture quality in the visible-light and near infrared light regions and high sensitivity.
The IMX178 is also equipped with Sony's Exmor R technology, which enhances imaging characteristics performances, such as high sensitivity and low noise.
- Related Documents
|Product Name||SONY IMX178LQJ-C|
|Shutter Type||Rolling Shutter|
|Recording Pixels||3072(H) x 2048(V)|
|Pixel Size||2.4µm x 2.4µm|
|Maximal Frame Rate @Full Resolution|
|Interface||sub LVDS Serial (4, 8, 10 lanes)|
