TAMRON SMA11F25

Tamron released its first Machine Vision lens for a spectral range from visible to Short Wavelength Infrared (SWIR).

The new SMA11F25 lens has a sensor size of 1”, a 25mm focal length and a 5µm pixel pitch. With a very low TV distortion of only -1% and a F# of only 1.6, this lens is the perfect choice for Industrial Applications like Food Processing or in the Medical field.

Product Name

TAMRON SMA11F25

Manufacturer

Tamron

Sensor Size

1"

Focal Length

25mm

Mount

C-mount

F-number

1.6 - 22

Minimum Object Distance

0.2m

Field of View

1"         29.1° x 21.9°

2/3"    20.1° x 15.1°

1/2"    14.7° x 11.7°

Filter Thread

M46 P=0.75

SMA11F25
pdf FILE
